Tractor 4 in 1 Bucket

Tractor 4 in 1 bucket for digging, clamping, levelling, and material handling

On farms and work sites, tasks often shift between digging, moving material, levelling ground, and handling debris. Using separate attachments for each job slows down operations and increases machine downtime. A tractor 4 in 1 bucket allows operators to switch between functions without changing attachments, improving efficiency across daily work. The Kerfab Tractor 4 in 1 Bucket is designed to deliver multiple functions in a single attachment, allowing digging, dozing, clamping, and levelling from one setup. The bucket can open to grab material such as logs or rocks, or operate as a standard bucket for scooping and dumping. With a range of widths from 1580 mm to 2400 mm and capacities up to 0.60 m³, it provides a balanced solution for tractors and ag loaders across varied applications.
icon tools-solid-svgrepo-com
Multi-function design for digging, clamping, dozing, and levelling
Icon - Heavy-duty
Hardened cutting edge with optional teeth and wear edges
Icon - Width
Available in widths from 1580 mm to 2400 mm
icon weight-svgrepo-com
Capacities from 0.30 m³ to 0.60 m³
icon shipping-fast-svgrepo-com
Despatch within 7 working days of order confirmation
Icon - Warranty
Backed by a 2 year standard warranty + 2 year registered warranty

Designed for:

Digging and moving soil
Levelling and spreading material
Handling logs and debris
Cleaning up paddocks and yards
General farm and site work

Machine Compatibility

Ag Loader
Bespoke

When requesting a quote, include your machine make and model so the correct hitch configuration can be recommended.

Performance Benefits

icon gear-wheel-svgrepo-com
Replaces multiple attachments
One attachment can perform several tasks, reducing the need for equipment changes.
noun-adaptive-7110686
Improves workflow efficiency
Operators can switch between tasks without leaving the cab or changing tools.
icon farm-svgrepo-com
Handles a wide range of materials
Suitable for soil, debris, logs, and general material handling across farm operations.
Icon- ticks
Reduces downtime between tasks
Less time spent changing attachments improves productivity.
product-required
Supports versatile daily use
Designed for varied tasks across agricultural and site environments.

Engineering design

See it in 3D

Multi-function bucket design

The bucket opens and closes to allow clamping, dozing, and standard loading functions in one attachment.

Hardened cutting edge system

Cutting edge is hardened for durability, with optional teeth and bolt-on wear edges available.

Replaceable pivot bushes

Self-lubricating bushes are fitted to main pivot points, supporting smooth operation and reduced wear.

Reinforced bucket structure

The bucket is designed to manage load transfer across multiple functions, maintaining strength under varied tasks.

Specifications

Part Number
Width mm
Capacity m3
Number of teeth option
U41.ES16
1530
0.3
6
U41.ES18
1840
0.4
7
U41.AS15
1580
0.3
6
U41.AS18
1800
0.34
7
U41.AS21
2100
0.4
9
U41.LA18
1800
0.45
8
U41.LA21
2100
0.52
9
U41.LA24
2400
0.60
10

See it in action

Play Video

Documents

Tractor 4 in 1 Bucket

Product Information Sheet

Icon - Operation Manual
Operation Manual
Refer to the Identification Plate on the bucket for the specifications relevant to this attachment.

FAQ

What is a tractor 4 in 1 bucket used for?
A tractor 4 in 1 bucket is used for digging, clamping, levelling, and moving materials. It allows multiple tasks to be completed with one attachment.
It can handle soil, rocks, logs, and general debris. The clamping function allows irregular materials to be secured during handling.
Yes. The bucket is available in widths from 1580 mm to 2400 mm with capacities up to 0.60 m³. This allows it to be matched to different tractor sizes and applications.

Get a Quote

Tell us your machine type, make and model, and the job the attachment will be used for.

Our team will confirm the correct configuration and provide a quote.

Most quotes are returned within one business day.




Our team will review your machine compatibility and respond with the correct attachment configuration and pricing.

Description

On farms and work sites, tasks often shift between digging, moving material, levelling ground, and handling debris. Using separate attachments for each job slows down operations and increases machine downtime. A tractor 4 in 1 bucket allows operators to switch between functions without changing attachments, improving efficiency across daily work.

The Kerfab Tractor 4 in 1 Bucket is designed to deliver multiple functions in a single attachment, allowing digging, dozing, clamping, and levelling from one setup. The bucket can open to grab material such as logs or rocks, or operate as a standard bucket for scooping and dumping. With a range of widths from 1580 mm to 2400 mm and capacities up to 0.60 m³, it provides a balanced solution for tractors and ag loaders across varied applications.

Additional information

Part number

A4115, A4117, A4118, A4119, A4121
