Mixer Bucket

Concrete Mixer Bucket

Concrete mixer bucket attachment for on-site mixing and controlled concrete placement

Mixing and placing concrete on site often requires multiple machines and extra handling, especially when working in areas with limited access. Transporting mixed concrete can lead to delays or inconsistent placement if conditions change across the job. A concrete mixer bucket attachment allows operators to mix, carry, and pour concrete directly from the machine, keeping the process contained and controlled. The Kerfab Concrete Mixer Bucket integrates loading, mixing, transport, and discharge into a single attachment. An enclosed drum and auger system maintains consistent material flow, while Hardox 500 mixing propellers support durability when working with abrasive aggregates. Built-in bag opener spikes on the grid simplify loading, and controlled discharge allows concrete to be placed accurately where needed across site conditions.
icon gear-wheel-svgrepo-com
Mix, transport, and pour concrete from one attachment
Icon - Heavy-duty
Hardox 500 mixing propellers for wear resistance
cut-svgrepo-com
Built-in bag opener spikes for faster loading
Icon - Compatible
Operates using a single hydraulic circuit
icon weight-svgrepo-com
Capacity range from 200L to 1800L
Icon - Warranty
Backed by a 2 year standard warranty + 2 year registered warranty
Get a Quote

Designed for:

Pouring footings and foundations
Fence line concreting
Working in tight or restricted access areas
Construction and civil works
On-site mixing and placement tasks

Machine Compatibility

Ag Loader
Skid Steer
Telehandler
Wheel Loader
Bespoke

When requesting a quote, include your machine make and model so the correct hitch configuration can be recommended.

Get a Quote

Performance Benefits

icon tools-solid-svgrepo-com
Reduces the need for multiple machines
Mixing and placement are handled in one attachment. This reduces reliance on separate mixers and transport equipment.
Icon- ticks
Improves accuracy when placing concrete
Controlled discharge allows concrete to be placed exactly where needed. This is useful in confined or detailed work areas.
bale-of-hay-svgrepo-com
Maintains consistency during mixing
The enclosed system keeps material moving evenly. This helps produce a more consistent mix across batches.
construction-svgrepo-com (2)
Supports work in restricted access areas
Large trucks or mixers cannot always reach the job. The attachment allows concrete to be delivered directly from the machine.
icon bucket-svgrepo-com
Handles a range of job sizes
Multiple capacity options allow the attachment to be matched to different project requirements. This supports both small and larger pours.

Engineering design

Mixer Bucket

Enclosed drum system

The drum and auger system is enclosed to manage material flow. This supports consistent mixing and discharge.

Hardox mixing components

Mixing propellers are manufactured from Hardox 500 steel. This improves wear resistance when handling abrasive materials.

Hydraulic drive system

The bucket operates using a single hydraulic circuit. This simplifies machine integration and operation.

Integrated loading grid

A protective grid supports safe loading. Built-in spikes assist with breaking open cement bags during loading.

Specifications

Part No
Capacity (Lt)
Height (mm)
Total Width (mm)
Weight* Empty Load** (kg)
Weight* Full Load** (kg)
Recommended Oil Flow (Lt)
Max Oil Flow (Lt)
TBU.MX02
250
750
1550
350
900
40
75
TBU.MX03
350
750
1700
400
1170
50
90
TBU.MX04
400
1000
1650
580
1460
65
90
TBU.MX05
500
1050
1950
700
1800
70
150
TBU.MX07
750
1200
2050
900
2550
125
240
TBU.MX10
1000
1300
2100
950
3150
125
240
WBU.MX15
1500
1600
2150
1750
5050
40
75
WBU.MX18
1800
1600
2350
1800
5760
40
75

Please note:

*Weights may vary depending on the type of attachment and optional equipment used.

**Specific weight of concrete is 2400 kg/m3.

See it in action

Play Video

Documents

Concrete Mixer Bucket

Product Information Sheet

Download

FAQ

What is a concrete mixer bucket attachment used for?
A concrete mixer bucket attachment is used to mix, transport, and pour concrete directly from a loader. It combines multiple steps into one process, improving efficiency on site.
The attachment is available in capacities ranging from 200L to 1800L. This allows it to be matched to both machine size and job requirements.
Concrete is discharged through a controlled outlet system. This allows operators to place material accurately without needing to reposition the machine frequently.
